Outdoor
NoxWall Light
| Wattage |
2 - 10 X5W |
|---|---|
| Lumens |
490 - 2390 |
– Robust exterior die-cast aluminium wall light
– Multi CCT Selectable from 3,000K and 4,000K
– Weather resistant anodised paint finish
– Aluminium optical reflector for enhanced performance and distribution
At a glance:
| Product Code | Spec sheet | Product Name | Wattage (W) | Output (lm) | Lm/W | CCT (K) | Colour Temp Selectable (CTS) | CTS Number | CRI | Beam Angle | Colour / Finish | IP Rating | IK Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S-NX-WL/2X4/CTS/B | Download | Nox Wall Light 2X4W Up&Down IP65 - Black | 2X5W | 2200 | 110 | 3000K/4000K | Y | 2 | 80 | 36° | Black | IP65 | IK08 |
| S-NX-WL/2X9/CTS/B | Download | Nox Wall Light 2X9W Up&Down IP65 - Black | 2X10W | 1130 | 115 | 3000K/4000K | Y | 2 | 80 | 36° | Black | IP65 | IK08 |
| S-NX-WL/2X4/CTS/W | Download | Nox Wall Light 2X4W Up&Down IP65 - White | 2X5W | 2390 | 120 | 3000K/4000K | Y | 2 | 80 | 36° | White | IP65 | IK08 |
| S-NX-WL/2X9/CTS/W | Download | Nox Wall Light 2X9W Up&Down IP65 - White | 2X10W | 1230 | 125 | 3000K/4000K | Y | 2 | 80 | 36° | White | IP65 | IK08 |
| S-NX-WL/2X4/CTS/GR | Download | Nox Wall Light 2X4W Up&Down IP65 - Grey | 2X5W | 2200 | 110 | 3000K/4000K | Y | 2 | 80 | 36° | Grey | IP65 | IK08 |
| S-NX-WL/2X9/CTS/GR | Download | Nox Wall Light 2X9W Up&Down IP65 - Grey | 2X10W | 1130 | 115 | 3000K/4000K | Y | 2 | 80 | 36° | Grey | IP65 | IK08 |
| S-NX-WL/5/CTS/B | Download | Nox Wall Light 5W Down CTS IP65 - Black | 5W | 490 | 96 | 3000K/4000K | Y | 2 | 80 | 36° | Black | IP65 | IK08 |
| S-NX-WL/5/CTS/W | Download | Nox Wall Light 5W Down CTS IP65 - White | 5W | 530 | 105 | 3000K/4000K | Y | 2 | 80 | 36° | White | IP65 | IK08 |
| S-NX-WL/5/CTS/GR | Download | Nox Wall Light 5W Down CTS IP65 - Grey | 5W | 490 | 96 | 3000K/4000K | Y | 2 | 80 | 36° | Grey | IP65 | IK08 |
| S-NX-WL/10/CTS/B | Download | Nox Wall Light 10W Down IP65 - Black | 10W | 1050 | 105 | 3000K/4000K | Y | 2 | 80 | 36° | Black | IP65 | IK08 |
| S-NX-WL/10/CTS/W | Download | Nox Wall Light 10W Down IP65 - White | 10W | 1140 | 114 | 3000K/4000K | Y | 2 | 80 | 36° | White | IP65 | IK08 |
| S-NX-WL/10/CTS/GR | Download | Nox Wall Light 10W Down IP65 - Grey | 10W | 1050 | 105 | 3000K/4000K | Y | 2 | 80 | 36° | Grey | IP65 | IK08 |
