Indoor
PaxxBulkhead
| Wattage |
8 - 20 W |
|---|---|
| Lumens |
1,000 - 2,400 |
– Slim and modern IP65 bulkhead
– Design elements to facilitate ultra-fast installation with modular attachments for Microwave and Emergency conversions
– PC diffuser engineered by designed to achieved IP65, IK08
– Multi CCT Selectable from 3,000K, 4,000K, 5,000K and 6,500K
– Multi output / power options with 3 options
– Toolless replaceable modular design
At a glance:
| Product Code | Spec sheet | Product Name | CCT (K) | Wattage (W) | Output (lm) | Lm/W | Colour Temp Selectable (CTS) | CTS Number | CRI | Beam Angle | Colour / Finish | IP Rating | IK Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S-PXX-28/CTS/W | Download | Paxx Bulkhead 28 CTS IP65 - White | 3000K/4000K/6500K | 8W / 10W / 12W | 1,000 / 1,200 / 1,450 | 120 | Y | 3 | 80 | 110° | White | IP65 | IK08 |
| S-PXX-28/CTS/EM3/W | Download | Paxx Bulkhead 28 CTS EM3 IP65 - White | 3000K/4000K/6500K | 8W / 10W / 12W | 1,000 / 1,200 / 1,450 | 120 | Y | 3 | 80 | 110° | White | IP65 | IK08 |
| S-PXX-32/CTS/W | Download | Paxx Bulkhead 32 CTS IP65 - White | 3000K/4000K/6500K | 12W / 16W / 20W | 1,680 / 1,920 / 2,400 | 120 | Y | 3 | 80 | 110° | White | IP65 | IK08 |
| S-PXX-32/CTS/EM3/W | Download | Paxx Bulkhead 32 CTS EM3 IP65 - White | 3000K/4000K/6500K | 12W / 16W / 20W | 1,680 / 1,920 / 2,400 | 120 | Y | 3 | 80 | 110° | White | IP65 | IK08 |
-
Modular Acc -
Modular Acc
ModuleEM Emergency Module
View
