Indoor
PhotosDlight
| Wattage |
9 - 24 W |
|---|---|
| Lumens |
1,030 - 3,300 |
– UGR < 19 140Lm/W high efficiency recessed downlight
– Faceted reflective polished aluminium reflector for optimal performance
– Multi CCT Selectable from 3,000K, 4,000K and 6,500K
– Multi output / power options with 4 options per size
– Dimmable and Emergency options available.
At a glance:
| Product Code | Spec sheet | Product Name | Wattage (W) | Output (lm) | Lm/W | CCT (K) | Colour Temp Selectable (CTS) | CTS Number | CRI | Beam Angle | UGR | Colour / Finish | IP Rating | IK Rating | Cut Out (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S-PH-145/CTS/W | Download | Photos Dlight 145 CTS IP54 - White | 9W/10W/11W/12W | 1,030 / 1,170 / 1,340 / 1,500 | 125 | 3000K/4000K/6500K | Y | 3 | 80 | 60° | <19 | White | IP54 | IK03 | 120-130 |
| S-PH-190/CTS/W | Download | Photos Dlight 190 CTS IP54 - White | 12W/16W/20W/24W | 1,600 / 2,180 / 2,680 / 3,100 | 140 | 3000K/4000K/6500K | Y | 3 | 80 | 60° | <19 | White | IP54 | IK03 | 160-170 |
| S-PH-228/CTS/W | Download | Photos Dlight 228 CTS IP54 - White | 12W/16W/20W/24W | 1,630 / 2,230 / 2,750 / 3,300 | 140 | 3000K/4000K/6500K | Y | 3 | 80 | 60º | <19 | White | IP54 | IK03 | 200-201 |
-
